MC33486ADHR2 دیتاشیت

MC33486ADHR2

مشخصات دیتاشیت

نام دیتاشیت MC33486ADHR2
حجم فایل 921.868 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت MC33486ADHR2

دانلود دیتاشیت

سایر مستندات

MC33486 Series 30 pages

مشخصات فنی

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: High Side (2)
  • Interface: Parallel
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 10A
  • Voltage - Supply: 8V ~ 28V
  • Voltage - Load: 8V ~ 28V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 20-SOIC (0.433", 11.00mm Width) Exposed Pad
  • Supplier Device Package: 20-HSOP
  • Base Part Number: MC334
  • detail: Motor Driver Power MOSFET Parallel 20-HSOP
