MAX77801EWP+T دیتاشیت

MAX77801EWP+T

مشخصات دیتاشیت

نام دیتاشیت MAX77801EWP+T
حجم فایل 79.579 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت MAX77801EWP+T

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX77801 31 pages

MAX77801EWP+T 31 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Buck-boost type
  • Topology: Step-down-Boost
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX77801EWP+T
  • Output Type: Adjustable
  • Input Voltage: 2.3V~5.5V
  • Output Voltage: 2.6V~4.19V
  • Number of Outputs: 1
  • Switching Frequency: 2.5MHz
  • Output Current (Max): 2A
  • Operating Temperature: -40°C~+85°C@(TA)
  • Synchronous Rectification: Yes
  • Package: WLP-20(1.83x2.13)
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Voltage - Input (Max): 5.5V
  • Voltage - Input (Min): 2.3V
  • Output Configuration: Positive
  • Supplier Device Package: 20-WLP (1.83x2.13)
  • Package / Case: 20-WFBGA, WLBGA
  • Frequency - Switching: 2.5MHz
  • Current - Output: 2A
  • Part Status: Active
  • Series: -
  • Voltage - Output (Max): 4.19V
  • Base Part Number: MAX77801
  • Mounting Type: Surface Mount
  • Synchronous Rectifier: Yes
  • Voltage - Output (Min/Fixed): 2.6V
  • Packaging: Cut Tape (CT)
  • detail: Buck-Boost Switching Regulator IC Positive Programmable 2.6V 1 Output 2A 20-WFBGA, WLBGA
