PMN25UN,115 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
PMN25UN
|
|
حجم فایل
|
1127.3
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
17
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
6A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Rds On (Max) @ Id, Vgs:
27mOhm @ 6A, 4.5V
-
Vgs(th) (Max) @ Id:
1V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
10nC @ 4.5V
-
Vgs (Max):
±8V
-
Input Capacitance (Ciss) (Max) @ Vds:
470pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
530mW (Ta), 6.25W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-TSOP
-
Package / Case:
SC-74, SOT-457
-
Base Part Number:
PMN2
-
detail:
N-Channel 20V 6A (Ta) 530mW (Ta), 6.25W (Tc) Surface Mount 6-TSOP
