- BFG67,BFG67/X(R)
BFG67/X,215 Datasheet
Datasheet specifications
| Datasheet's name | BFG67,BFG67/X(R) |
|---|---|
| File size | 294.297 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet BFG67,BFG67/X(R) |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: NXP USA Inc.
- Series: -
- Packaging: Digi-Reel®
- Part Status: Obsolete
- Transistor Type: NPN
- Voltage - Collector Emitter Breakdown (Max): 10V
- Frequency - Transition: 8GHz
- Noise Figure (dB Typ @ f): 1.3dB @ 1GHz
- Gain: -
- Power - Max: 380mW
- DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 15mA, 5V
- Current - Collector (Ic) (Max): 50mA
- Operating Temperature: 175°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-253-4, TO-253AA
- Supplier Device Package: SOT-143B
- Base Part Number: BFG67
- detail: RF Transistor NPN 10V 50mA 8GHz 380mW Surface Mount SOT-143B
