- دیتاشیت MAX1595ETC50+
MAX1595ETC50+ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX1595ETC50+ |
|---|---|
| حجم فایل | 91.866 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت MAX1595ETC50+ |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX1595 7 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Buck-boost type
- Topology: -
- Datasheet: Analog Devices Inc./Maxim Integrated MAX1595ETC50+
- Output Type: Fixed
- Input Voltage: 1.8V~5.5V
- Output Voltage: 5V
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Output Current (Max): 125mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: QFN-12-EP(4x4)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 5.5V
- Voltage - Input (Min): 1.8V
- Output Configuration: Positive
- Supplier Device Package: 12-TQFN (4x4)
- Package / Case: 12-WQFN Exposed Pad
- Frequency - Switching: 1MHz
- Current - Output: 125mA
- Part Status: Active
- Series: -
- Voltage - Output (Max): -
- Base Part Number: MAX1595
- Mounting Type: Surface Mount
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 5V
- Packaging: Tube
- detail: Charge Pump Switching Regulator IC Positive Fixed 5V 1 Output 125mA 12-WQFN Exposed Pad
