PIC16(L)F183xx Brief Datasheet
Datasheet specifications
| Datasheet's name | PIC16(L)F183xx Brief |
|---|---|
| File size | 242.009 KB |
| File type | |
| Number of pages | 23 |
Download Datasheet PIC16(L)F183xx Brief |
Download Datasheet |
|---|
Other documentations
PIC16(L)F18324,44 489 pages
PIC16LF18324-I/SL 489 pages
Technical specifications
- RoHS: true
- EEPROM: 256Byte
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): 5bit
- Datasheet: Microchip Tech PIC16LF18324-E/ST
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 12
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 7KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: TSSOP-14
- Manufacturer: Microchip Tech
- Series: PIC® XLP™ 16F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 32MHz
- Connectivity: I²C, LINbus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 12
- Program Memory Size: 7KB (4K x 14)
- EEPROM Size: 256 x 8
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 11x10b; D/A 1x5b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 14-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 14-TSSOP
- Base Part Number: PIC16LF18324
- detail: PIC PIC® XLP™ 16F Microcontroller IC 8-Bit 32MHz 7KB (4K x 14) FLASH 14-TSSOP
