PCA9509 Datasheet

PCA9509

Datasheet specifications

Datasheet's name PCA9509
File size 308.844 KB
File type pdf
Number of pages 24

Download Datasheet PCA9509

Download Datasheet

Other documentations

PCA9509 24 pages

Technical specifications

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Type: Buffer, ReDriver
  • Applications: I²C
  • Input: 2-Wire Bus
  • Output: 2-Wire Bus
  • Data Rate (Max): 400kHz
  • Number of Channels: 2
  • Delay Time: -
  • Signal Conditioning: -
  • Capacitance - Input: 2pF
  • Voltage - Supply: 3V ~ 5.5V
  • Current - Supply: 3mA
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SO
  • Base Part Number: PCA95
  • detail: Buffer, ReDriver 2 Channel 400kHz 8-SO
