MAX680CSA+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX680CSA+T |
|---|---|
| حجم فایل | 92.433 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
دانلود دیتاشیت MAX680CSA+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX680-681 9 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: -
- Topology: -
- Datasheet: Analog Devices Inc./Maxim Integrated MAX680CSA+T
- Output Type: Fixed
- Input Voltage: 2V~6V
- Number of Outputs: 2
- Switching Frequency: 8kHz
- Output Current (Max): 10mA
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SO-8
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 6V
- Voltage - Input (Min): 2V
- Output Configuration: Positive and Negative (Dual Rail)
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Frequency - Switching: 8kHz
- Current - Output: 10mA
- Part Status: Active
- Series: -
- Voltage - Output (Max): -
- Base Part Number: MAX680
- Mounting Type: Surface Mount
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): ±2Vin
- Packaging: Cut Tape (CT)
- detail: Charge Pump Switching Regulator IC Positive and Negative (Dual Rail) Fixed ±2Vin 2 Output 10mA 8-SOIC (0.154", 3.90mm Width)
