- Datasheet MCP1827(S, ST, T)
MCP1827(S, ST, T) Datasheet
Datasheet specifications
| Datasheet's name | MCP1827(S, ST, T) |
|---|---|
| File size | 699.873 KB |
| File type | |
| Number of pages | 34 |
Download Datasheet MCP1827(S, ST, T) |
Download Datasheet |
|---|
Other documentations
MCP1827S-3002E/AB 34 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MCP1827S-0802E/EB
- Output Current: 1.5A
- Output Voltage: 0.8V
- Dropout Voltage: 0.6V@(1.5A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 220uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
- Package: TO-252-3
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 6V
- Voltage - Output (Min/Fixed): 0.8V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.6V @ 1.5A
- Current - Output: 1.5A
- Current - Quiescent (Iq): 220µA
- PSRR: 60dB (100Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
- Mounting Type: Surface Mount
- Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- Supplier Device Package: 3-DDPAK
- Base Part Number: MCP1827S
- detail: Linear Voltage Regulator IC 1 Output 1.5A 3-DDPAK
