技术规格
- Manufacturer: NXP USA Inc.
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Number of I/O: 8
- Interface: I²C
- Interrupt Output: Yes
- Features: POR
- Output Type: Push-Pull
- Current - Output Source/Sink: 300µA, 25mA
- Clock Frequency: 100kHz
- Voltage - Supply: 2.5V ~ 6V
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-DIP
- Base Part Number: PCF85
- detail: I/O Expander 8 I²C 100kHz 16-DIP
