دیتاشیت MCP8063T-E/MD

MCP8063

مشخصات دیتاشیت

نام دیتاشیت MCP8063
حجم فایل 467.425 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت MCP8063

MCP8063 Datasheet

مشخصات

  • RoHS: true
  • Type: 无刷直流BLDC
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Microchip Tech MCP8063T-E/MD
  • Interface: PWM
  • Output Current: 1.5A
  • Supply Voltage: 2V~14V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: DFN-8-EP(4x4)
  • Manufacturer: Microchip Tech
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushless DC (BLDC)
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (3)
  • Technology: DMOS
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 1.5A
  • Voltage - Supply: 2V ~ 14V
  • Voltage - Load: 2V ~ 14V
  • Mounting Type: Surface Mount
  • Package / Case: 8-VDFN Exposed Pad
  • Supplier Device Package: 8-DFN-EP (4x4)
  • Base Part Number: MCP8063
  • detail: Motor Driver DMOS PWM 8-DFN-EP (4x4)
