دیتاشیت BSP304A,126

BSP304, BSP304A

مشخصات دیتاشیت

نام دیتاشیت BSP304, BSP304A
حجم فایل 55.653 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت BSP304, BSP304A

BSP304, BSP304A Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 300V
  • Current - Continuous Drain (Id) @ 25°C: 170mA (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 17Ohm @ 170mA, 10V
  • Vgs(th) (Max) @ Id: 2.55V @ 1mA
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 90pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 1W (Ta)
  • Operating Temperature: -65°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Base Part Number: BSP3
  • detail: P-Channel 300V 170mA (Ta) 1W (Ta) Through Hole TO-92-3
