دیتاشیت BUK7615-100A,118

BUK7615-100A

مشخصات دیتاشیت

نام دیتاشیت BUK7615-100A
حجم فایل 56.805 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت BUK7615-100A

BUK7615-100A Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: TrenchMOS™
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 100V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 15mOhm @ 25A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 1mA
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 6000pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 230W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: D2PAK
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Base Part Number: BUK76
  • detail: N-Channel 100V 75A (Tc) 230W (Tc) Surface Mount D2PAK
