دیتاشیت BUK9608-55,118

BUK9608-55

مشخصات دیتاشیت

نام دیتاشیت BUK9608-55
حجم فایل 57.018 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت BUK9608-55

BUK9608-55 Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: TrenchMOS™
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 55V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 5V
  • Rds On (Max) @ Id, Vgs: 8mOhm @ 25A, 5V
  • Vgs(th) (Max) @ Id: 2V @ 1mA
  • Vgs (Max): ±10V
  • Input Capacitance (Ciss) (Max) @ Vds: 6900pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 187W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: D2PAK
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Base Part Number: BUK96
  • detail: N-Channel 55V 75A (Tc) 187W (Tc) Surface Mount D2PAK
