دیتاشیت PHP110NQ06LT,127

PHB110NQ06LT

مشخصات دیتاشیت

نام دیتاشیت PHB110NQ06LT
حجم فایل 214.893 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت PHB110NQ06LT

PHB110NQ06LT Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: TrenchMOS™
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 55V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 7mOhm @ 25A, 10V
  • Vgs(th) (Max) @ Id: 2V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 45nC @ 5V
  • Vgs (Max): ±15V
  • Input Capacitance (Ciss) (Max) @ Vds: 3960pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 200W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220AB
  • Package / Case: TO-220-3
  • Base Part Number: PHP11
  • detail: N-Channel 55V 75A (Tc) 200W (Tc) Through Hole TO-220AB
