دیتاشیت PDTA114ES,126

مشخصات دیتاشیت

دانلود دیتاشیت PDTA114E Series	PDTA114E Series Datasheet

Manufacturer: NXP USA Inc.
Series: -
Packaging: Tape & Box (TB)
Part Status: Obsolete
Transistor Type: PNP - Pre-Biased
Current - Collector (Ic) (Max): 100mA
Voltage - Collector Emitter Breakdown (Max): 50V
Resistor - Base (R1): 10 kOhms
Resistor - Emitter Base (R2): 10 kOhms
DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 5mA, 5V
Vce Saturation (Max) @ Ib, Ic: 150mV @ 500µA, 10mA
Current - Collector Cutoff (Max): 1µA
Power - Max: 500mW
Mounting Type: Through Hole
Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Supplier Device Package: TO-92-3
Base Part Number: PDTA11
detail: Pre-Biased Bipolar Transistor (BJT) PNP - Pre-Biased 50V 100mA 500mW Through Hole TO-92-3
