دیتاشیت LX8213-00ISE-TR
مشخصات دیتاشیت
| نام دیتاشیت |
LX8213
|
| حجم فایل |
288.268
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Adjustable
-
Number of Regulators:
1
-
Voltage - Input (Max):
6V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
5.5V
-
Voltage Dropout (Max):
0.17V @ 300mA
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
90µA
-
PSRR:
68dB ~ 54dB (100Hz ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-74A, SOT-753
-
Supplier Device Package:
SOT-23-5
-
detail:
Linear Voltage Regulator IC 1 Output 300mA SOT-23-5
