دیتاشیت PHP75NQ08T,127

PHP75NQ08T

مشخصات دیتاشیت

نام دیتاشیت PHP75NQ08T
حجم فایل 182.194 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت PHP75NQ08T

PHP75NQ08T Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: TrenchMOS™
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 75V
  • Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 13mOhm @ 25A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 40nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 1985pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 157W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220AB
  • Package / Case: TO-220-3
  • Base Part Number: PHP75
  • detail: N-Channel 75V 75A (Tc) 157W (Tc) Through Hole TO-220AB
