- PSMN005-25D
PSMN005-25D,118 Datasheet
Datasheet specifications
| Datasheet's name | PSMN005-25D |
|---|---|
| File size | 152.686 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet PSMN005-25D |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: NXP USA Inc.
- Series: TrenchMOS™
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 25V
- Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
- Rds On (Max) @ Id, Vgs: 5.8mOhm @ 25A, 10V
- Vgs(th) (Max) @ Id: 2V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 60nC @ 5V
- Vgs (Max): ±15V
- Input Capacitance (Ciss) (Max) @ Vds: 3500pF @ 20V
- FET Feature: -
- Power Dissipation (Max): 125W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: DPAK
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Base Part Number: PSMN0
- detail: N-Channel 25V 75A (Tc) 125W (Tc) Surface Mount DPAK
