دیتاشیت PN2369A,126
مشخصات دیتاشیت
| نام دیتاشیت |
PN2369A
|
| حجم فایل |
56.204
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Tape & Box (TB)
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
200mA
-
Voltage - Collector Emitter Breakdown (Max):
15V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 10mA, 100mA
-
Current - Collector Cutoff (Max):
400nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
40 @ 10mA, 350mV
-
Power - Max:
500mW
-
Frequency - Transition:
500MHz
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
PN23
-
detail:
Bipolar (BJT) Transistor NPN 15V 200mA 500MHz 500mW Through Hole TO-92-3
