MC705C8ACPE Datasheet

MC68(HC,HSC)705C8A

Datasheet specifications

Datasheet's name MC68(HC,HSC)705C8A
File size 3802.143 KB
File type pdf
Number of pages 222

Download Datasheet MC68(HC,HSC)705C8A

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: NXP USA Inc.
  • Series: HC05
  • Packaging: Tube
  • Part Status: Obsolete
  • Core Processor: HC05
  • Core Size: 8-Bit
  • Speed: 2.1MHz
  • Connectivity: SCI, SPI
  • Peripherals: POR, WDT
  • Number of I/O: 24
  • Program Memory Size: 8KB (8K x 8)
  • Program Memory Type: OTP
  • EEPROM Size: -
  • RAM Size: 304 x 8
  • Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
  • Data Converters: -
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Through Hole
  • Package / Case: 40-DIP (0.600", 15.24mm)
  • Supplier Device Package: 40-PDIP
  • Base Part Number: MC705
  • detail: HC05 HC05 Microcontroller IC 8-Bit 2.1MHz 8KB (8K x 8) OTP 40-PDIP
