دیتاشیت VN0550N3-G-P013

VN0550

مشخصات دیتاشیت

نام دیتاشیت VN0550
حجم فایل 921.9 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت VN0550

VN0550 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Microchip Tech VN0550N3-G-P013
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 1W
  • Drain Source Voltage (Vdss): 500V
  • Input Capacitance (Ciss@Vds): 55pF@25V
  • Continuous Drain Current (Id): 50mA
  • Gate Threshold Voltage (Vgs(th)@Id): 4V@1mA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 60Ω@50mA,10V
  • Package: TO-92-3
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tape & Box (TB)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 50mA (Tj)
  • Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
  • Rds On (Max) @ Id, Vgs: 60Ohm @ 50mA, 10V
  • Vgs(th) (Max) @ Id: 4V @ 1mA
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 55pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 1W (Tc)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • detail: N-Channel 500V 50mA (Tj) 1W (Tc) Through Hole TO-92-3
