دیتاشیت 74HC112N,652
مشخصات دیتاشیت
| نام دیتاشیت |
74HC(T)112
|
| حجم فایل |
94.974
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
Manufacturer:
NXP USA Inc.
-
Series:
74HC
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Function:
Set(Preset) and Reset
-
Type:
JK Type
-
Output Type:
Differential
-
Number of Elements:
2
-
Number of Bits per Element:
1
-
Clock Frequency:
71MHz
-
Max Propagation Delay @ V, Max CL:
30ns @ 6V, 50pF
-
Trigger Type:
Negative Edge
-
Current - Output High, Low:
5.2mA, 5.2mA
-
Voltage - Supply:
2V ~ 6V
-
Current - Quiescent (Iq):
4µA
-
Input Capacitance:
3.5pF
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
16-DIP
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Base Part Number:
74HC11
-
detail:
Flip Flop 2 Element JK Type 1 Bit Negative Edge 16-DIP (0.300", 7.62mm)
