دیتاشیت 74ABT16823ADGG,118

مشخصات دیتاشیت

دانلود دیتاشیت 74ABT16823A	74ABT16823A Datasheet

Manufacturer: NXP USA Inc.
Series: 74ABT
Packaging: Tape & Reel (TR)
Part Status: Obsolete
Function: Master Reset
Type: D-Type
Output Type: Tri-State, Non-Inverted
Number of Elements: 2
Number of Bits per Element: 9
Clock Frequency: 190MHz
Max Propagation Delay @ V, Max CL: 3.2ns @ 5V, 50pF
Trigger Type: Positive Edge
Current - Output High, Low: 32mA, 64mA
Voltage - Supply: 4.5V ~ 5.5V
Current - Quiescent (Iq): 1mA
Input Capacitance: 4pF
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Supplier Device Package: 56-TSSOP
Package / Case: 56-TFSOP (0.240", 6.10mm Width)
Base Part Number: 74ABT16
detail: Flip Flop 2 Element D-Type 9 Bit Positive Edge 56-TFSOP (0.240", 6.10mm Width)
