MIC2267 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MIC2267	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Microchip Tech MIC2267YML-TR
Output Type: Adjustable
Input Voltage: 3V~5.5V
Output Voltage: 1V~5.5V
Number of Outputs: 1
Switching Frequency: 1.5MHz
Output Current (Max): 500mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: DFN-12-EP(3x3)
Manufacturer: Microchip Tech
Series: USB Power Maximizer™
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 1V
Voltage - Output (Max): 5.5V
Current - Output: 500mA
Frequency - Switching: 400kHz ~ 1.5MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 12-VFDFN Exposed Pad, 12-MLF®
Supplier Device Package: 12-MLF™ (3x3)
Base Part Number: MIC2267
detail: Buck Switching Regulator IC Positive Adjustable 1V 1 Output 500mA 12-VFDFN Exposed Pad, 12-MLF®
