دیتاشیت TDA5140AT/C1,112

TDA5140A

مشخصات دیتاشیت

نام دیتاشیت TDA5140A
حجم فایل 178.555 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت TDA5140A

TDA5140A Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushless DC (BLDC)
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (3)
  • Interface: Parallel
  • Technology: Bipolar
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 1A
  • Voltage - Supply: 4V ~ 18V
  • Voltage - Load: 1.7V ~ 16V
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 20-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 20-SO
  • Base Part Number: TDA514
  • detail: Motor Driver Bipolar Parallel 20-SO
