دیتاشیت BUT11APX-1200,127

BUT11APX-1200

مشخصات دیتاشیت

نام دیتاشیت BUT11APX-1200
حجم فایل 63.124 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت BUT11APX-1200

BUT11APX-1200 Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 6A
  • Voltage - Collector Emitter Breakdown (Max): 550V
  • Vce Saturation (Max) @ Ib, Ic: 1V @ 400mA, 2A
  • Current - Collector Cutoff (Max): 1mA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 20 @ 500mA, 5V
  • Power - Max: 32W
  • Frequency - Transition: -
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3 Full Pack, Isolated Tab
  • Supplier Device Package: TO-220F
  • Base Part Number: BUT11
  • detail: Bipolar (BJT) Transistor NPN 550V 6A 32W Through Hole TO-220F
