MAX626MJA/883B دیتاشیت

MAX626MJA/883B

مشخصات دیتاشیت

نام دیتاشیت MAX626MJA/883B
حجم فایل 93.787 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

مشاهده دیتاشیت MAX626MJA/883B

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX626,7,8, TSC426,7,8 5 pages

MAX62xMxx/883B, TSC42xMxx/883B 3 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX626MJA/883B
  • Fall Time: 20ns
  • Load Type: MOSFET
  • Rise Time: 25ns
  • Supply Voltage: 4.5V~18V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: -55°C~+125°C@(Ta)
  • Peak Output Current(sink): 2A
  • Peak Output Current(source): 2A
  • Package: CERDIP-8
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Current - Peak Output (Source, Sink): 2A, 2A
  • Supplier Device Package: 8-CERDIP
  • Base Part Number: MAX626
  • Input Type: Inverting
  • Gate Type: N-Channel, P-Channel MOSFET
  • Part Status: Active
  • Channel Type: Independent
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Series: Military, MIL-STD-883
  • Mounting Type: Through Hole
  • Package / Case: 8-CDIP (0.300", 7.62mm)
  • Packaging: Tube
  • Voltage - Supply: 4.5V ~ 18V
  • Rise / Fall Time (Typ): 25ns, 20ns
  • detail: Low-Side Gate Driver IC Inverting 8-CERDIP
