- دیتاشیت PIC24FJ256GA705 Family Datasheet
دیتاشیت PIC24FJ256GA705 Family Datasheet
مشخصات دیتاشیت
| نام دیتاشیت | PIC24FJ256GA705 Family Datasheet |
|---|---|
| حجم فایل | 3372.444 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 424 |
PIC24FJ256GA705 Family Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
PIC24FJ256GA705 Family Errata, Clarification 12 pages
PIC24FJ256GA702-I/SS 424 pages
مشخصات فنی
- RoHS: true
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Datasheet: Microchip Tech PIC24FJ64GA705-I/M4
- Package: UQFN-48-EP(6x6)
- Manufacturer: Microchip Tech
- Series: PIC® 24F
- Packaging: Tray
- Part Status: Active
- Core Processor: PIC
- Core Size: 16-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, LINbus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT
- Number of I/O: 40
- Program Memory Size: 64KB (22K x 24)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 16K x 8
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 14x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-UFQFN Exposed Pad
- Supplier Device Package: 48-UQFN (6x6)
- Base Part Number: PIC24FJ64GA705
- detail: PIC PIC® 24F Microcontroller IC 16-Bit 32MHz 64KB (22K x 24) FLASH 48-UQFN (6x6)
