دیتاشیت TDF8590TH/N1S,118

مشخصات دیتاشیت

دانلود دیتاشیت TDF8590TH	TDF8590TH Datasheet

Manufacturer: NXP USA Inc.
Series: -
Packaging: Tape & Reel (TR)
Part Status: Obsolete
Type: Class D
Output Type: 1-Channel (Mono) or 2-Channel (Stereo)
Max Output Power x Channels @ Load: 160W x 1 @ 8Ohm; 80W x 2 @ 4Ohm
Voltage - Supply: ±14V ~ 29V
Features: Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C (TA)
Supplier Device Package: 24-HSOP
Package / Case: 24-BSOP (0.433", 11.00mm Width) Exposed Pad
Base Part Number: TDF859
detail: Amplifier IC 1-Channel (Mono) or 2-Channel (Stereo) Class D 24-HSOP
