MAX631AMJA/883B دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MAX631AMJA/883B	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Analog Devices Inc./Maxim Integrated MAX631AMJA/883B
Output Type: 可调和固定
Input Voltage: 2.4V~16.5V
Number of Outputs: 1
Switching Frequency: 45kHz
Output Current (Max): 450mA
Operating Temperature: -55°C~+125°C@(TA)
Synchronous Rectification: NO
Package: CERDIP-8
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 16.5V
Voltage - Input (Min): 2.4V
Output Configuration: Positive
Supplier Device Package: 8-CERDIP
Package / Case: 8-CDIP (0.300", 7.62mm)
Frequency - Switching: 45kHz
Current - Output: 450mA (Switch)
Part Status: Active
Series: -
Voltage - Output (Max): 16.5V
Base Part Number: MAX631
Mounting Type: Through Hole
Synchronous Rectifier: No
Voltage - Output (Min/Fixed): 2.4V (5V)
Packaging: Tube
detail: Boost Switching Regulator IC Positive Adjustable (Fixed) 2.4V (5V) 1 Output 450mA (Switch) 8-CDIP (0.300", 7.62mm)
