دیتاشیت TDA3664AT/N1/N,118
مشخصات دیتاشیت
| نام دیتاشیت | TDA3664 |
|---|---|
| حجم فایل | 93.094 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت TDA3664 |
TDA3664 Datasheet |
|---|
مشخصات
- Manufacturer: NXP USA Inc.
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 45V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.3V @ 50mA
- Current - Output: 100mA
- Current - Quiescent (Iq): 30µA
- Current - Supply (Max): 2.5mA
- PSRR: 60dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit, Transient Voltage
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO
- Base Part Number: TDA366
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-SO
