MAX307CWI+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX307CWI+T |
|---|---|
| حجم فایل | 99.187 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MAX307CWI+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX306,307 12 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX307CWI+T
- Turn-on time: 200ns
- Turn-off time: 150ns
- Supply Voltage: 5V~30V
- Number of Channels: 2
- On-State Resistance (Max): 100Ω
- Package: SOP-28-300mil
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 8:1
- Part Status: Active
- Charge Injection: 2pC
- -3db Bandwidth: -
- Operating Temperature: 0°C ~ 70°C (TA)
- Voltage - Supply, Dual (V±): ±4.5V ~ 20V
- Supplier Device Package: 28-SOIC
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
- Switch Time (Ton, Toff) (Max): 200ns, 150ns
- Packaging: Cut Tape (CT)
- Channel-to-Channel Matching (ΔRon): 1.5Ohm
- Voltage - Supply, Single (V+): 5V ~ 30V
- Channel Capacitance (CS(off), CD(off)): 8pF, 65pF
- Switch Circuit: -
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -92dB @ 100kHz
- Number of Circuits: 2
- Current - Leakage (IS(off)) (Max): 500pA
- Base Part Number: MAX307
- detail: 2 Circuit IC Switch 8:1 100Ohm 28-SOIC
