دیتاشیت MIC22405YML-TR
مشخصات دیتاشیت
| نام دیتاشیت |
MIC22405
|
| حجم فایل |
1766.805
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Microchip Tech MIC22405YML-TR
-
Output Type:
Adjustable
-
Input Voltage:
2.9V~5.5V
-
Output Voltage:
0.7V~5.5V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
4A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
MLF-20
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.9V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.7V
-
Voltage - Output (Max):
5.5V
-
Current - Output:
4A
-
Frequency - Switching:
1MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
20-VFQFN Exposed Pad, 20-MLF®
-
Supplier Device Package:
20-MLF® (3x4)
-
Base Part Number:
MIC22405
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.7V 1 Output 4A 20-VFQFN Exposed Pad, 20-MLF®
