دیتاشیت PIC16LF1778-I/SO
مشخصات دیتاشیت
| نام دیتاشیت | PIC16(L)F1777,8,9 Datasheet |
|---|---|
| حجم فایل | 8023.818 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 628 |
دانلود دیتاشیت PIC16(L)F1777,8,9 Datasheet |
PIC16(L)F1777,8,9 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 128Byte
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): 5bit;10bit
- Datasheet: Microchip Tech PIC16LF1778-I/SO
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 25
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 28KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: SOP-28-300mil
- Manufacturer: Microchip Tech
- Series: PIC® XLP™ 16F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 32MHz
- Connectivity: I²C, LINbus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 25
- Program Memory Size: 28KB (16K x 14)
- EEPROM Size: 128 x 8
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 17x10b; D/A 3x5b, 3x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 28-SOIC
- Base Part Number: PIC16LF1778
- detail: PIC PIC® XLP™ 16F Microcontroller IC 8-Bit 32MHz 28KB (16K x 14) FLASH 28-SOIC
