دیتاشیت LD6816CX4/13H,315

LD6816 Series

مشخصات دیتاشیت

نام دیتاشیت LD6816 Series
حجم فایل 1283.237 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LD6816 Series

LD6816 Series Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.075V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 100µA
  • Current - Supply (Max): 250µA
  • PSRR: 55dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Transient Voltage
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 4-XFBGA, WLCSP
  • Supplier Device Package: 4-WLCSP (0.76x0.76)
  • Base Part Number: LD681
  • detail: Linear Voltage Regulator IC 1 Output 150mA 4-WLCSP (0.76x0.76)
