PCA9515ATP,147 Datasheet

PCA9515A

Datasheet specifications

Datasheet's name PCA9515A
File size 222.189 KB
File type pdf
Number of pages 20

Download Datasheet PCA9515A

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Type: Buffer, ReDriver
  • Applications: I²C
  • Input: 2-Wire Bus
  • Output: 2-Wire Bus
  • Data Rate (Max): 400kHz
  • Number of Channels: 1
  • Delay Time: -
  • Signal Conditioning: -
  • Capacitance - Input: 6pF
  • Voltage - Supply: 2.3V ~ 3.6V
  • Current - Supply: 800µA
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-WFDFN Exposed Pad
  • Supplier Device Package: 8-HWSON (2x3)
  • Base Part Number: PCA95
  • detail: Buffer, ReDriver 1 Channel 400kHz 8-HWSON (2x3)
