دیتاشیت DG302ACJ+

DG300A-303A

مشخصات دیتاشیت

نام دیتاشیت DG300A-303A
حجم فایل 339.205 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت DG300A-303A

DG300A-303A Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 2:1
  • Part Status: Active
  • Charge Injection: 12pC
  • -3db Bandwidth: -
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Voltage - Supply, Dual (V±): ±5V ~ 18V
  • Supplier Device Package: 14-PDIP
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Switch Time (Ton, Toff) (Max): 300ns, 250ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): -
  • Voltage - Supply, Single (V+): -
  • Channel Capacitance (CS(off), CD(off)): 14pF, 14pF
  • Switch Circuit: DPST - NO
  • Mounting Type: Through Hole
  • Series: -
  • Crosstalk: -74dB @ 500kHz
  • Number of Circuits: 2
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 5nA
  • Base Part Number: DG302A
  • On-State Resistance (Max): 50Ohm
  • detail: 2 Circuit IC Switch 2:1 50Ohm 14-PDIP
