TJA1052I Datasheet
Datasheet specifications
| Datasheet's name | TJA1052I |
|---|---|
| File size | 278.236 KB |
| File type | |
| Number of pages | 27 |
Download Datasheet TJA1052I |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: NXP USA Inc.
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Technology: Capacitive Coupling
- Type: CAN
- Isolated Power: No
- Number of Channels: 1
- Inputs - Side 1/Side 2: 1/1
- Channel Type: Unidirectional
- Voltage - Isolation: 1000Vrms
- Common Mode Transient Immunity (Min): 20kV/µs
- Data Rate: 5Mbps
- Propagation Delay tpLH / tpHL (Max): -
- Pulse Width Distortion (Max): -
- Rise / Fall Time (Typ): -
- Voltage - Supply: 3V ~ 5.25V
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SO
- Base Part Number: TJA105
- detail: CAN Digital Isolator 1000Vrms 1 Channel 5Mbps 20kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
