MIC2131-1YML-TR 数据手册
其他文档
MIC2130,31 20 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Datasheet: Microchip Tech MIC2131-1YML-TR
- Package: MLF-16
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 8V ~ 40V
- Frequency - Switching: 150kHz
- Duty Cycle (Max): 92%
- Synchronous Rectifier: Yes
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Current Limit, Enable, Power Good, Soft Start
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 16-VQFN Exposed Pad, 16-MLF®
- Supplier Device Package: 16-MLF® (4x4)
- Base Part Number: MIC2131
- detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-MLF® (4x4)
