دیتاشیت DS3231MZ+TRL

DS3231M

مشخصات دیتاشیت

نام دیتاشیت DS3231M
حجم فایل 912.296 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت DS3231M

DS3231M Datasheet

مشخصات

  • RoHS: true
  • Category: RTC/Clock Chip/Real-time Clocks (RTC)
  • Datasheet: Analog Devices Inc./Maxim Integrated DS3231MZ+TRL
  • Interface: I2C
  • Operating Voltage: 2.3V~5.5V
  • Operating Temperature: -40°C~+85°C
  • Package: SOP-8
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Features: Alarm, Leap Year, Square Wave Output
  • Supplier Device Package: 8-SOIC
  • Voltage - Supply, Battery: 2.3V ~ 5.5V
  • Date Format: YY-MM-DD-dd
  • Memory Size: -
  • Part Status: Active
  • Type: Clock/Calendar
  • Series: -
  • Time Format: HH:MM:SS (12/24 hr)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Current - Timekeeping (Max): 130µA ~ 200µA @ 3.63V ~ 5.5V
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 2.3V ~ 5.5V
  • Base Part Number: DS3231
  • detail: Real Time Clock (RTC) IC Clock/Calendar I²C, 2-Wire Serial 8-SOIC (0.154", 3.90mm Width)
