MAX4704EUB+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX4704EUB+T |
|---|---|
| حجم فایل | 90.763 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MAX4704EUB+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX4704 11 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX4704EUB+T
- Turn-on time: 60ns
- Turn-off time: 20ns
- Supply Voltage: 1.8V~5.5V
- Switch Circuit: 单刀四掷(SP4T)
- Number of Channels: 1
- On-State Resistance (Max): 60Ω
- Package: UMAX-10
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 4:1
- Part Status: Active
- Charge Injection: 2pC
- -3db Bandwidth: 200MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): -
- Supplier Device Package: 10-uMAX
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Switch Time (Ton, Toff) (Max): 60ns, 20ns
- Packaging: Tape & Reel (TR)
- Channel-to-Channel Matching (ΔRon): 1Ohm
- Voltage - Supply, Single (V+): 1.8V ~ 5.5V
- Channel Capacitance (CS(off), CD(off)): 7pF
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -90dB @ 1MHz
- Number of Circuits: 1
- Current - Leakage (IS(off)) (Max): 100pA
- Base Part Number: MAX4704
- detail: 1 Circuit IC Switch 4:1 60Ohm 10-uMAX
