MAX1947ETA33+T دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX1947ETA33+T	دانلود دیتاشیت

MAX1947 11 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Analog Devices Inc./Maxim Integrated MAX1947ETA33+T
Output Type: Fixed
Input Voltage: 0.7V~3.6V
Output Voltage: 3.3V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 169mA
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: DFN-8(3x3)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 3.6V
Voltage - Input (Min): 0.7V
Output Configuration: Positive
Supplier Device Package: 8-TDFN-EP (3x3)
Package / Case: 8-WDFN Exposed Pad
Frequency - Switching: Up to 2MHz
Current - Output: 169mA
Part Status: Discontinued at Digi-Key
Series: -
Voltage - Output (Max): -
Base Part Number: MAX1947
Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Voltage - Output (Min/Fixed): 3.3V
Packaging: Cut Tape (CT)
detail: Boost Switching Regulator IC Positive Fixed 3.3V 1 Output 169mA 8-WDFN Exposed Pad
