دیتاشیت MAX4610ESD+T

مشخصات دیتاشیت

MAX4610ESD+T	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices Inc./Maxim Integrated MAX4610ESD+T
Turn-on time: 65ns
Turn-off time: 28ns
Supply Voltage: 2V~12V
Switch Circuit: SPST(SPST)-Normal Open
Number of Channels: 4
On-State Resistance (Max): 100Ω
Package: SOIC-14
Manufacturer: Analog Devices Inc./Maxim Integrated
Multiplexer/Demultiplexer Circuit: 1:1
Part Status: Active
Charge Injection: 1pC
-3db Bandwidth: 300MHz
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply, Dual (V±): -
Supplier Device Package: 14-SOIC
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Switch Time (Ton, Toff) (Max): 65ns, 28ns
Packaging: Tape & Reel (TR)
Channel-to-Channel Matching (ΔRon): 1Ohm
Voltage - Supply, Single (V+): 2V ~ 12V
Channel Capacitance (CS(off), CD(off)): 16pF, 16pF
Mounting Type: Surface Mount
Series: -
Crosstalk: -80dB @ 1MHz
Number of Circuits: 4
Current - Leakage (IS(off)) (Max): 100pA
Base Part Number: MAX4610
detail: 4 Circuit IC Switch 1:1 100Ohm 14-SOIC
