MAX20078ATE/VY+T 数据手册
其他文档
MAX20078 Datasheet 22 pages
MAX20078 Abridged Datasheet 22 pages
技术规格
- RoHS: true
- Type: DC-DCController
- Dimming: Analog;PWM
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 1
- Topology: Step-down
- Datasheet: Analog Devices Inc./Maxim Integrated MAX20078ATE/VY+T
- Input Voltage: 4.5V~65V
- Output Current: 10mA
- Switch Frequency: 1MHz
- Operating temperature: -40°C~+125°C
- Package: QFN-16-EP(3x3)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Applications: Automotive, Lighting
- Number of Outputs: 1
- Supplier Device Package: 16-TQFN-EP (3x3)
- Internal Switch(s): No
- Voltage - Supply (Min): 4.5V
- Package / Case: 16-WFQFN Exposed Pad
- Part Status: Active
- Voltage - Supply (Max): 65V
- Series: Automotive, AEC-Q100
- Base Part Number: MAX20078
- Mounting Type: Surface Mount
- Voltage - Output: -
- Frequency: 1MHz
- Packaging: Tube
- Current - Output / Channel: 10mA
- detail: LED Driver IC 1 Output DC DC Controller Step-Down (Buck) Analog, PWM Dimming 10mA 16-TQFN-EP (3x3)
