MCIMX6G2CVM05AA دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MCIMX6G2CVM05AA	دانلود دیتاشیت

RoHS: true
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Datasheet: NXP Semicon MCIMX6G2CVM05AA
Package: BGA-289
Manufacturer: NXP Semicon
Series: i.MX6UL
Packaging: Tray
Part Status: Obsolete
Core Processor: ARM® Cortex®-A7
Number of Cores/Bus Width: 1 Core, 32-Bit
Speed: 528MHz
Co-Processors/DSP: Multimedia; NEON™ SIMD
RAM Controllers: LPDDR2, DDR3, DDR3L
Graphics Acceleration: No
Display & Interface Controllers: LCD, LVDS
Ethernet: 10/100Mbps (2)
SATA: -
USB: USB 2.0 + PHY (2)
Voltage - I/O: 1.2V, 1.35V, 1.5V, 1.8V, 2.5V, 2.8V, 3.3V
Operating Temperature: -40°C ~ 105°C (TJ)
Security Features: ARM TZ, A-HAB, CAAM, CSU, SJC, SNVS
Package / Case: 289-LFBGA
Supplier Device Package: 289-MAPBGA (14x14)
Additional Interfaces: CAN, EBI/EMI, I²C, I²S, MMC/SD/SDIO, QSPI, SAI, SPI, SSI, S/PDIF, UART
Base Part Number: MCIMX6
detail: ARM® Cortex®-A7 Microprocessor IC i.MX6UL 1 Core, 32-Bit 528MHz 289-MAPBGA (14x14)
