IRFL9110TRPBF Datasheet

IRFL9110TRPBF

Datasheet specifications

Datasheet's name IRFL9110TRPBF
File size 104.139 KB
File type pdf
Number of pages 9

Download Datasheet IRFL9110TRPBF

Download Datasheet

Other documentations

IRFL9110TRPBF 8 pages

Technical specifications

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Vishay Intertech IRFL9110TRPBF
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 2W;3.1W
  • Total Gate Charge (Qg@Vgs): 8.7nC@10V
  • Drain Source Voltage (Vdss): 100V
  • Input Capacitance (Ciss@Vds): 200pF@25V
  • Continuous Drain Current (Id): 1.1A
  • Gate Threshold Voltage (Vgs(th)@Id): 4V@250uA
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 1.2Ω@660mA,10V
  • Package: SOT-223-3
  • Manufacturer: Vishay Intertech
  • Part id: 251362
