دیتاشیت SMBJ300CA

SMBJ300CA

مشخصات دیتاشیت

نام دیتاشیت SMBJ300CA
حجم فایل 469.691 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

دانلود دیتاشیت SMBJ300CA

SMBJ300CA Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: RUILON(Shenzhen Ruilongyuan Elec) SMBJ300CA
  • Breakdown Voltage: 335V
  • Maximum Clamping Voltage: 486V
  • Reverse Leakage Current (Ir): 1uA
  • Reverse Stand-Off Voltage (Vrwm): 300V
  • Peak Pulse Current (Ipp)@10/1000us: 1.3A
  • Package: SMB(DO-214AA)
  • Manufacturer: RUILON(Shenzhen Ruilongyuan Elec)
  • Type: -
  • Polarity: Bi-Directional
  • Machine Model: -
  • Number of Lines: -
  • Human Body Model: -
  • Clamping Voltage@Ipp: 486V
  • Operating Temperature: -55°C~+150°C
  • Contact Discharge Vesd: 30kV
  • Breakdown Voltage (VBR): 371V
  • Reverse Leakage Current: 1mA
  • Peak Pulse Power(Ppp)@8/20us: 600W
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: 1.3A
  • Bidirectional Channels: 1
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
  • Part id: 610919
