BC856S Datasheet

BC856S

Datasheet specifications

Datasheet's name BC856S
File size 37.923 KB
File type pdf
Number of pages 5

Download Datasheet BC856S

Download Datasheet

Other documentations

BC856S 6 pages

BC856S 4 pages

Technical specifications

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: Jiangsu Changjing Electronics Technology Co., Ltd. BC856S
  • Package: SOT-323-6
  • Manufacturer: Jiangsu Changjing Electronics Technology Co., Ltd.
  • Transistor Type: 2PCSPNP
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Collector Current (Ic): 100mA
  • Power Dissipation (Pd): 200mW
  • Transition Frequency (fT): 100MHz
  • DC Current Gain (hFE@Ic,Vce): 110@2mA,5V
  • Collector Cut-Off Current (Icbo): 15nA
  • Collector-Emitter Breakdown Voltage (Vceo): 65V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 650mV@100mA,5mA
  • Part id: 44312
