AHEF300 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse AHEF300
- Hold Current: 3A
- Trip Current: 6A
- Power Dissipation: 3.2W
- Current Rating (Max): 100A
- Maximum Time to Trip: 5s
- Operating Temperature: -40°C~+125°C
- Operating Voltage (Max): 32V
- Resistance - Initial (Ri) (Min): 35mΩ
- Resistance - Post Trip (R1) (Max): 110mΩ
- Package: Plugin
- Manufacturer: Littelfuse
- Part id: 604146
